1934 Replica/Kit Makes Mercedes-Benz

These cars were replicated by Heritage Industries from the late 1980's to early 1990's. They were manufactured in kit form and as a completed auto. Kit forms started in price from $15. 00. 00 and went up from there depending on options. That pricing did not include donor car components needed for completion. A completed factory built car started at about $50. 00. 00 and went up from there depending on options. Not sure on productin numbers of either the kits or completed autos. These cars are thought to be one of the best in replication of the original Mercedes Benz 500 K.

This auto was purchase in an unassembled condition with only the chassis being remotely assembled. Most all components present were in their original packaging and new condition. The fiberglass components were built extremely thick and durable including gel coat applicpation. The kit was designed with a steel body subframe assembly. that once the fiberglass panels were installed was cushion mounted to the main chassis frame.

This auto built with care and concern to functionality. The frame and Camaro front subframe was reworked and welded into a complete assembly. The engine mounts were designed and fabricated as bolt in units totally eliminating the original design that had a fixed crossmember under the engine oil pan. The rear spring hangers were also redesigned and fabricated to bolt to the frame. The body subframe mounts were also fabricated as bolt on to the frame assembly. The original kit included many formed plastic panels which included the dash assembly. The dash was completely redesigned and custom built as the supplied plastic dash obstructed driver and passenger entry into the car. The dash includes a sub dash framework with removable exterior panels along with console assembly.

Newly built and several years in the building of this classic roadster with attention to functionality and detail. Many extra items built into this car that you would not typically see in similar Heritage cars out there being driven or offered for sale. For example. fabricated and installed under running board shielding from behind the front wheels to the front of the rear wheels. They are designed to be easily unbolted and removed if necessary. The shielded area behind the right front wheel (where the battery is mounted) is hinged for battery removal and or replacement. Interior body and trunk panels are also removable. Most all fasteners are grade 8 or stainless. Assembly instruction manual is also included with this auto. but not always followed. For example many screws and pop rivets were designed to be used in construction of this auto and they were not in this 500 K !! The car body was painted silver with fenders in black. The paint is base/clear coat system.

Could go on and on about this labor of love. but will end by listing some of the components and features built into this fine MB 500 K Roadster.
GM 305 TPI fuel injected engine 700 R 4 4 speed automatic overdrive transmission GM 10 bolt posi rear axle GM tilt steering column with ignition shifter lock 4 wheel power disc brakes with parking brake Quick ratio power steering A/C. heater and defrost JVC Radio/CD with Bluetooth/MP 3. hands free telephone and 4 speaker sound system Power antenna-radio controlled Remote start. door lock and un-lock Door operated courtesy lights Trunk operated courtesy lights Under hood access lights Front and back fender mounted LED side marker/turn signal lights Back up lights 3 rd brake light. fog lights. 3 spot lights. custom top of fender turn signal/marker lights and dual trumpet horns Power windows Cruise control
Customs built ram air cleaner assembly with dual elements Under hood remote battery jumper posts with battery cut off switch Dual aluminized exhaust system with components flange mounted Full compliment of VDO white faced gaugesl 3 point seat belts Front and rear sway bars 1934 Ford style entry door handles Custom built cloth convertible top with glass rear window Custom built hood side panels easily removable for access Carpeted through out with additional removable carpets Ready to cruise and enjoy!Call
